G3412
- Displacement
- 1649 in³ / 27 l
- Bore
- 5.4 in / 137 mm
- Stroke
- 6 in / 152 mm
Using natural gas for combined heat and power (CHP) systems and emergency power for facilities, to renewable biogas energy to support the local grid, or electricity generated from coal mine gases, Caterpillar has a wide range of reliable gas power solutions.
| Generator Set Specifications | |
|---|---|
| Continuous Rating | 423 ekW @0.8pf |
| Fuel Type | Natural Gas, Biogas, Field Gas, Propane |
| Maximum Electrical Efficiency | 37.30% |
| Maximum Standby Rating | 500 ekW @ 0.8pf |
| Frequency | 50 or 60 Hz |
| RPM | 1500 or 1800 rpm |
| Engine Specifications | |
|---|---|
| Engine Model | G3412 |
| Displacement | 1649 in³ / 27 l |
| Aspiration | NA |
| Bore | 5.4 in / 137 mm |
| Stroke | 6 in / 152 mm |
| Generator Set Dimensions | |
|---|---|
| Length | 179 in / 4542 mm |
| Width | 88 in / 2238 mm |
| Height | 86 in / 2189 mm |
| Dry Weight - Genset | 9664 lb / 4384 kg |
