3512B
- Maximum Power
- 1650 hp / 1231 kW
- Maximum Torque
- 5296 lb-ft @ 1450 rpm / 7180 Nm @ 1450 rpm
- Minimum Power
- 1500 hp / 1119 kW
For your largest power needs in any environment, Cat?? 3512B Industrial Diesel Engines offer the unsurpassed performance and durability your customers need to keep their industrial applications and operations running. They deliver high power output, proven reliability and excellent fuel efficiency. These engines maintain low operating costs to keep your customers profitable for years to come. Industries and applications powered by 3512B engines include Bore/Drill Rigs, Chippers/Grinders, Construction, Cranes, Dredgers, Forestry, General Industrial, Material Handling, Mining, Mobile Earthmoving Equipment, Pumps, Shovels/Draglines, Surface Hauling Equipment and Trenchers. These 3512B engines, with ratings: 1119-1231 bkW (1500-1650 bhp) @ 1800 rpm, are non-certified. They are available for global non-regulated areas.
| Power Rating | |
|---|---|
| Maximum Power | 1650 hp / 1231 kW |
| Maximum Torque | 5296 lb-ft @ 1450 rpm / 7180 Nm @ 1450 rpm |
| Rated Speed | 1800 rpm |
| Minimum Power | 1500 hp / 1119 kW |
| Emission Standards | |
|---|---|
| Emissions | Non-Certified |
| General | |
|---|---|
| Engine Configuration | V-12, 4-Stroke-Cycle Diesel |
| Bore | 6.7 in / 170 mm |
| Stroke | 7.5 in / 190 mm |
| Displacement | 3158 in³ / 51.8 l |
| Aspiration | Turbocharged Aftercooled |
| Rotation from Flywheel End | Counterclockwise |
| Aftertreatment | - |
| Engine Dimensions - Approximate | |
|---|---|
| Length | 120.8 in / 3067 mm |
| Width | 70.3 in / 1785 mm |
| Height | 71.1 in / 1806 mm |
| Weight - Net Dry - Basic Operating Engine Without Optional Attachments | 13400 lb / 6078 kg |
