CG170B-16
- Bore
- 6.7 in / 170 mm
- Stroke
- 7.7 in / 195 mm
- Length
- 240 in / 6100 mm
State-of-the-art components providing more power: the compact design, a focus on a wide range of applications and highest efficiency values of its class make sure of that. Managed by a smart and secure control system, the new CG170B series offers the optimal balance between profitability and reliability.
| Generator Set Specifications | |
|---|---|
| Continuous Rating | 1840 ekW @1.0pf |
| Fuel Type | Natural Gas, Biogas, Coal Gas, Hydrogen Blend (up to 25%) |
| Maximum Electrical Efficiency | 44.70% |
| Maximum Standby Rating | 1840 |
| Frequency | 50 Hz |
| RPM | 1500 rpm |
| Engine Specifications | |
|---|---|
| Engine Model | CG170B-16 |
| Aspiration | TA |
| Bore | 6.7 in / 170 mm |
| Stroke | 7.7 in / 195 mm |
| Generator Set Dimensions | |
|---|---|
| Length | 240 in / 6100 mm |
| Width | 67 in / 1710 mm |
| Height | 86 in / 2190 mm |
| Dry Weight - Genset | 38360 lb / 17400 kg |
